Deburring system
Pneumatic drive. (Max. width of bevel 2 mm / 0.08 in.) Designed for deburring and rounding edges of steel, stainless steel, aluminum and other workpieces. Suitable for machining holes from the internal diameter of 7 mm / 0.27 in.
Line
Art. Nr.
24220
Product Name
B2 AIR
Bevel Angle
45°
Rounding Radius
R 1,5 mm / R 0.06 in
Speed
23.000 rpm.
Feeding
manual
Air Consumption
320 l/min.
Weight
400 g / 0.88 lb
Dimensions
112 x 60 x 48 mm / 4.4 x 2.36 x 1.9 in
PRODUCT MANUALS
Bevel Types
V-Bevel
Radius
BEVEL TYPES
V-Bevel
Radius
